9inch TFT LCD Screen Pipeline Drain Sewer Inspection Video Camera 20M Cable Industrial Endoscope
This is aPipe Inspection Camera Systemkit for professional and daily working.It can be used for inspecting pipe lines, drains, wells, HVAC ductwork, general building inspection, and more.
This product is suitable to inspect the pipeline, sewer, air duct, tank, underwater and others dark environment, check the internal cracks, corrosion, weld, plugs and other unusual circumstance.
| Item | parameter |
| Monitor size | 9inch |
| Charger | AC100-240V DC12.6V 1000MA |
| Battery | lithium battery 12V4500MA |
| continuous use time for battery | approximate 6h |
| investigation depth | 20M( selectable line length) |
| material | fiber tube with /high intensity |
| camera working voltage | 5V |
| lights working voltage | 12V |
| camera material | stainless steel |
| Camera visual distance | 2-200CM (approximate) |
| camera picture | color |
| Operating temperature | -20-60° |
| Storage temperature | -50-60° |
Monitor
 | Monitor size | 9inch color TFT LCD display |
| Resolution | HD 720P | |
| Built | TF Card | |
| Support | Video recording |
Camera Head
 | Camera diameter | 23mm |
| Angle | 120 degree | |
| Waterproof | IP68 | |
| Applicable pipe diameter | >25MM | |
| Material | Stainless steel | |
| Light source | 12pcs LED Light |
Cable Reel
 | Cable length | 20M |
| Wire Type | Hard Wire | |
| Cable Material | Fiberglass | |
| Color | Yellow |
 | Battery capacity | 4500mAh |
| Power display | yes | |
| Work hours | About 6h | |
| Charger | AC100-240 DC12.6V 1000MA |
