Executive standard

It is manufactured acconding to MT 818.5-2009 standards.

Application

This product is a mine rubber set soft cable series products, suitable for rated voltage up to and including 0.66/1.14kV
connection
to the mobile devices such as coal device of the power supply circuit.

Using conditions

1.The rated voltage U0/U 0.38/0.66kV and including 0.66/1.14kV respectively;
2.Wire and the minimum bending radius is 6 times of cable diameter;
3.Cable should be good grounding earth core.

  Type and Designation


Type

Designation

Application
MY-0.38/0.66
Mining mobile rubber sheathed soft cable
0.38/0.66kV
Power connection to coal-mining machine under 0.38/0.66kV
MYP-0.38/0.66
Mining mobile screened rubber sheath soft cable
0.38/0.66kV
Power connection to coal-mining machine under 0.38/0.66kV
MYP-0.66/1.14
Mining mobile screened rubber sheath soft cable
0.66/1.14kV
Power connection to coal-mining machine under 0.66/1.14kV

  Spec. and Size

Core No. × section
(mm²)

Power line core insulation nominal thickness(mm)

Sheathed nominal thickness(mm)
Cable O.D.(mm)
MY-0.38/0.66
Min.Max.
1×502.02.418.522.5
1×702.02.621.025.0
1×952.22.823.528.5
1×1202.23.025.529.5
1×1502.43.228.033.0
1×1852.43.430.535.5
1×2405.63.534.039.5
1×3002.63.637.043.0
1×4002.83.842.048.0


Core No. × section
(mm²)


Power line core insulation
nominal thickness(mm)

Sheathed nominal
thickness(mm)
Cable O.D.(mm)
MY-0.38/0.66MYP-0.38/0.66

Power line

Ground line

Min.

Max.

Min.

Max.
3×41×41.43.519.022.522.026.5
3×61×61.43.521.025.524.029.0
3×101×101.64.025.030.028.032.5
3×161×101.64.027.532.030.535.5
3×251×161.84.532.537.535.541.0
3×351×161.84.535.541.038.544.5
3×501×162.05.041.547.538.551.0
3×701×252.05.046.053.049.056.0

Note: ground wire core section for minimum cross section.


Copper Mining Mobile Screened Rubber Sheath Soft Cable




Copper Mining Mobile Screened Rubber Sheath Soft Cable
Copper Mining Mobile Screened Rubber Sheath Soft Cable
Mine Cable Copper Class5 Rubber Sheath Shanghai Zone for Coal-Mining Control Cable Mining Factory Price


Copper Mining Mobile Screened Rubber Sheath Soft Cable


Copper Mining Mobile Screened Rubber Sheath Soft Cable




Copper Mining Mobile Screened Rubber Sheath Soft Cable


FAQ

Q1:Are you a trading company or manufacturer?

A1: Tianjin Feiya wire & Cable CO., LTD. is a professional manufacturer.

Q2: What kinds of products does Tianjin Feiya wire & Cable CO., LTD. manufacture?

A2: Our products mainly cover low, medium and high voltage (KV) crosslinked polyethylene insulated power cable,PVC insulated power cable, PVC insulated wire (construction cable), control cable, signal cable, rubber cable,coal mine cable, welding cable, ship cable and other related customized cables. These cables are used in Power metallurgy, Oil&Chemical Industry, Nation Defense Power Station, Mine, Port and Architectural Engineering, andother fields.

Q3:Which standards do you comply with when you produce the electrical wires and cables ?

A3: We have passed ISO9001:2000 and ISO140001:2004. All products conform to GB, IEC, BS, ASTM, VDE JB and UL standards. Besides, we have the ability to design and produce various wires and cables, and customize them for you according to the special requirements of customers (providing OEM services).

4: What is your MOQ?
A4: It`s base on the cable type or wire type. Please contact Calder. He will let you know.

Q5:How much the Courier freight will be for the samples?

A5:Courier freight depends on the quantity,weight and carton size and your area.
