HDPE Pipe Features:
1. Long working life. Minimum 50 years life under normal conditions.
2. Hygiene. PE pipe are nontoxic, without the composition of heavy metal additives. No scale, not breeding germ, no second pollution to the potable water.
3. High resistance to attack from various types of chemicals.
4. Smooth internal surface. Extremely low friction coefficient. Improved capability for media to pass through. Excellent abrasive resistance.
5. Good flexibility, high resistance to impact. Resistance to earthquake and twisting,brittle temperature could be -70°C.
6. Light weight, easy to transport, convenient installation.
7. Unique electric fusion welding and butt welding make the joints stronger than the material, to guarantee a safe and reliable joint.
8. Simple welding technique, convenient installation. Total cost is low for the installation.
9. Polyethylene water pipes are produced in black, black with blue stripes and blue etc
HDPE Pipe Connection:
Socket fusion, butt fusion joint, electric fusion joint, flange joint
HDPE Pipe Application:
1.Urban area water-supply work system. Large diameter PE pipe is healthy and non-toxic and more suitable for urban water supply main conduit and buried tube.
2.Replace cement tube, iron pipe and steel tube. Applicable for renovation project and does not need large area excavation, PE pipe can be widely used in old town of pipe network reconstruction.
3.Industrial materials transmission pipe. Chemical industry, chemical fiber, food, forestry, pharmacy, light industry and paper-making, metallurgical and other industrial raw material conveying pipe.
4.Landscaping water supply network. As landscaping project needs lots of water supply pipes, PE pipe is the best choice for its toughness and low costs.
5.Sewage discharge pipes. PE pipe have unique corrosion resistance, can be used in industrial waste water, sewage discharged pipe, low costs and maintenance costs .
6.Ore, mud transfers. PE pipe has high resistance to stress and wear resistance, can be widely applied in conveying ore, coal ash and river bait-casting mud.
7. Agricultural irrigation pipe. PE pipe has the merits of great flow and good impact resistance, it is the ideal tool for agricultural irrigation.
Details
| Items | hdpe pipe |
| material | Polyethylene |
| size | 16 ~ 1400 mm |
| color | Black |
| connection | Welding |
| pressure | PN6,PN8,PN10,PN12.5,PN16,PN20,PN25 |
| standard | ISO4427,AS/NZS4130 |
| Certification | ISO14001,OHSAS18001,ISO9001,CE |
| Nominal pressure | PN 0.6 MPa | PN 0.8 MPa | PN 1.0 MPa | PN 1.25 MPa | PN 1.6 MPa | PN 2.0MPa |
| Standard dimension ratio | SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 | SDR9 |
| Nominal outside diameter (mm) | Thickness(mm) | Thickness(mm) | Thickness(mm) | Thickness(mm) | Thickness(mm) | Thickness(mm) |
| Φ20 | 2.30 | 2.30 | ||||
| Φ25 | 2.30 | 2.30 | 3.00 | |||
| Φ32 | 2.30 | 2.40 | 3.00 | 3.60 | ||
| Φ40 | 2.30 | 2.40 | 3.00 | 3.70 | 4.50 | |
| Φ50 | 2.30 | 2.40 | 3.00 | 3.70 | 4.60 | 5.60 |
| Φ63 | 2.50 | 3.00 | 3.80 | 4.70 | 5.80 | 7.10 |
| Φ75 | 2.90 | 3.60 | 4.50 | 5.60 | 6.80 | 8.40 |
| Φ90 | 3.50 | 4.30 | 5.40 | 6.70 | 8.20 | 10.40 |
| Φ110 | 4.20 | 5.30 | 6.60 | 8.10 | 10.00 | 12.30 |
| Φ125 | 4.80 | 6.00 | 7.40 | 9.20 | 11.40 | 14.00 |
| Φ140 | 5.40 | 6.70 | 8.30 | 10.30 | 12.70 | 15.70 |
| Φ160 | 6.20 | 7.70 | 9.50 | 11.80 | 14.60 | 17.90 |
| Φ180 | 6.90 | 8.60 | 10.70 | 13.30 | 16.40 | 20.10 |
| Φ200 | 7.70 | 9.60 | 11.90 | 14.70 | 18.20 | 22.40 |
| Φ225 | 8.60 | 10.80 | 13.40 | 16.60 | 20.50 | 25.20 |
| Φ250 | 9.60 | 11.90 | 14.80 | 18.40 | 22.70 | 27.90 |
| Φ280 | 10.70 | 13.40 | 16.60 | 20.60 | 25.40 | 31.30 |
| Φ315 | 12.10 | 15.00 | 18.70 | 23.20 | 28.60 | 35.20 |
| Φ355 | 13.60 | 16.90 | 21.10 | 26.10 | 32.20 | 39.70 |
| Φ400 | 15.30 | 19.10 | 23.70 | 29.40 | 36.30 | 44.70 |
| Φ450 | 17.20 | 21.50 | 26.70 | 33.10 | 40.90 | 50.30 |
| Φ500 | 19.10 | 23.90 | 29.70 | 36.80 | 45.40 | 55.80 |
| Φ560 | 21.40 | 26.70 | 33.20 | 41.20 | 50.80 | 62.50 |
| Φ630 | 24.10 | 30.00 | 37.40 | 46.30 | 57.20 | 70.30 |
| Φ710 | 27.20 | 33.90 | 42.10 | 52.20 | 64.50 | 79.30 |
| Φ800 | 30.60 | 38.10 | 47.40 | 58.80 | 72.60 | 89.30 |
| Φ900 | 34.40 | 42.90 | 53.30 | 66.20 | 81.70 | |
| Φ1000 | 38.20 | 47.70 | 59.30 | 72.50 | 90.20 | |
| Φ1200 | 45.90 | 57.20 | 67.90 | 88.20 | ||
| Φ1400 | 53.50 | 66.70 | 82.40 | 102.90 |
Shandong Sifu International Trade Co.,Ltd.is a professional supplier of HDPE & PVC pipes, is the first national high-tech enterprise since lanshan District. The factory is located in shandong Province, and we have 5 years exporting experience, our factory covers more than 25,000 square meters. And we have 20 engineers and about more than 100 workers.
The company has first-class production equipment and advanced detection equipment , has accumulated a large number of professional and technical elites, specializing in R & D, production and sales of plastic products, metal products and rubber products. The annual production capacity of various types of products for company reaches 100000 tons.
FAQ
1.Q: What is the Raw material ?
A: 100% virgin raw material.
2.Q: What is your MOQ?
A: As customers' requests.
3.Q: why choose us?
A: We are a professional manufacturer with competitive price, good quality and fast delivery time.
4.Q: How to buy the product?
A: Send email to me, we will reply to you within one day.
5.Q: Can you make special Design and logo on product?
A: Yes, very easy.
6. Q: What is the shipping port?
A: Shanghai or Qingdao port.
